SKKT 57/16 E SCR/DIODE MODULE
Product Specifications, Documents & More
- SVHC No SVHC (15-Jun-2015)
- Peak Repetitive Off-State Voltage, Vdrm 1.6kV
- Gate Trigger Current Max, Igt 150mA
- Current It av 50A
- On State RMS Current IT(rms) 95A
- Thyristor Case Style Module
- No. of Pins 7Pins
- Peak Non Rep Surge Current Itsm 50Hz 1.5kA
- Holding Current Max Ih 250mA
- Gate Trigger Voltage Max Vgt 3V
- Operating Temperature Max 125°C
- Product Range -
- MSL -
- Technical Data Sheet (944.11KB) EN
