Power supply: 0... 256 V AC, 50/60 Hz
and 20 ... 240 V DC (no polarity)
Consumption: < 4 VA
Display: LCD screen
Ambient temperature: -10 ... +60 °C
Protection: IP 20
Mounting: Rail DIN 17.5 mm
Connections: 4 removable terminal blocks
Programming: Programming through a joystick or a PC
Multi-parameters input:
Current: 0...20 or 4...20 mA
Voltage: 0... 100 mV or 0 ... 10 V
Resistor thermometer: Pt 100 / Pt 1000, 2-wire or 3-wire sensors
R2-wire resistor: Ranges: 1 kΩ; 5 kΩ; 10 kΩ; 50 kΩ
PTC and NTC sensors: Scales: 1 kΩ; 5 kΩ; 10 kΩ; 50 kΩ;
programming with the software BLOG-CUB
Thermocouples: J, K, T, B, R, S, E, NiMo, N, W3/D, W5/C, P
Potentiometric input: From 470 Ω up to 100 kΩ
Power supply to sensor: 2-wire or 3-wire sensors: Max. 19V and 26 mA
2 Analogue outputs and 2 relay outputs:
Current: 0...20 and or 4...20 mA (Impedance < 700 Ω)
Voltage: 0...10 V (Impedance > 2 kΩ )
Relay: Change-over 500 mA / 250 V
CE conformity: The device meets the legal requirements of the current
European Directives.
Code Reference Description
233 200 CUB-233 Versatil converter
233 205 CUB Communication interface
233 206 BLOG-CUB Programming software
